Tempat asal:
Cina
Nama merek:
ANGES
Nomor model:
AM-24W
| Model | AM-6W | AM-9W | AM-12W | AM-18W | AM-24W | AM-36W | |
| Media perpindahan panas | Air | ||||||
| Suhu Maks | ℃ | 120 | |||||
| Daya pemanas | KW | 6 | 9 | 12 | 18 | 24 | 36 |
| Kekuasaan | 3PH-380V-50HZ | ||||||
| Daya pompa | HP | 0,5 | 1 | 0,5 | 1 | 2 | 3 |
| Laju aliran maksimum pompa | L/mnt | 42 | 56 | 98 | 165 | 235 | 315 |
| Pompa maks.tekanan | batang | 2.8 | 3.8 | 2 | 2.2 | 2.4 | 2.6 |
| Volume sedang | L | 3.2 | 3.2 | 4 | 4 | 8 | 8 |
| Metode pendinginan | Pendinginan langsung | ||||||
| Pendinginan Cetakan | lnch | 3/8"*2 | 3/8"*2 | 3/8"*4 | 3/8"*4 | 3/8"*4 | 3/8"*4 |
| Ukuran saluran masuk/keluar | lnch | 3/4"/3/4" | 3/4"/3/4" | 1"/1" | 1"/1" | 1"/1" | 1"/1" |
Dimensi (mm) |
H | 645 | 645 | 715 | 715 | 715 | 715 |
| W | 373 | 373 | 453 | 453 | 453 | 453 | |
| D | 745 | 745 | 882 | 882 | 882 | 882 | |
| Bobot | Kg | 55 | 60 | 65 | 75 | 90 | 110 |
